Solar Panel EVA Film Solar Cell Encapsulation EVA glue film. Thickness 0.3mm Width 200/500mm lenght 1000mm
$5.46
Condition: A brand-new, unused, unopened, undamaged item in its original packaging (where packaging is applicable). Packaging should be the same as what is found in a retail store, unless the item is handmade or was packaged by the manufacturer in non-retail packaging, such as an unprinted box or plastic bag. See the seller's listing for full details.
Description:
Tip: The product is pre cut. When you purchase multiple items, the received product will be discontinuous. Please make sure you don't mind purchasing again. Thank you!
Product Description
Brand new and high quality
0.3x200x1000mm / 0.3x500x1000mm
Thickness: 0.3mm
Width: 200 /500 mm
Length: 1000 mm
Laminating Steps
Laminating: laminate the glass, EVA film, connected silicon cells, EVA film, TPT backsheet foil in sequence.
Vacuum pumping: Place above laminated pieces into the lower room of the double-vacuum press. Then the upper room and the lower room are vacuumed synchronously about 6min.
Heating: the upper room and the lower room are kept vacuum, meanwhile heat the laminated pieces.
Press: Laminated pieces are heated under 135°C-140°C conditions, the upper room cancel vacuum and get back to atmospheric pressure. At that time the lower room is still kept vacuum, that is to say, the upper room press on the laminated pieces of the lower room.
Curing: Isothermal curing under the curing temperature.
Cooling and framing: After isothermal curing, cancel the vacuum of the lower room, open the top of the press, and take out the laminated modules. Then cut off the extra EVA of composite lamination edge. Moreover seal frame and equip the termainal box, assemble PV modules at last.
Packing quantity: 1pcs
(Delivery according to your choice)
Notice:
- Please refer to the measurement. Tiny measuring error is allowable in normal range.
- Please consider the actual sizes in the listing as the pictures are generally enlarged to show detail.
- There might be a little color difference due to the monitor, camera or other factors, please refer to the physical item.
- Due to different producing batches, product details might be a little different. If you minding the difference, please buy it carefully
Product Description
Brand new and high quality
0.3x200x1000mm / 0.3x500x1000mm
Thickness: 0.3mm
Width: 200 /500 mm
Length: 1000 mm
Laminating Steps
Laminating: laminate the glass, EVA film, connected silicon cells, EVA film, TPT backsheet foil in sequence.
Vacuum pumping: Place above laminated pieces into the lower room of the double-vacuum press. Then the upper room and the lower room are vacuumed synchronously about 6min.
Heating: the upper room and the lower room are kept vacuum, meanwhile heat the laminated pieces.
Press: Laminated pieces are heated under 135°C-140°C conditions, the upper room cancel vacuum and get back to atmospheric pressure. At that time the lower room is still kept vacuum, that is to say, the upper room press on the laminated pieces of the lower room.
Curing: Isothermal curing under the curing temperature.
Cooling and framing: After isothermal curing, cancel the vacuum of the lower room, open the top of the press, and take out the laminated modules. Then cut off the extra EVA of composite lamination edge. Moreover seal frame and equip the termainal box, assemble PV modules at last.
Packing quantity: 1pcs
(Delivery according to your choice)
Notice:
- Please refer to the measurement. Tiny measuring error is allowable in normal range.
- Please consider the actual sizes in the listing as the pictures are generally enlarged to show detail.
- There might be a little color difference due to the monitor, camera or other factors, please refer to the physical item.
- Due to different producing batches, product details might be a little different. If you minding the difference, please buy it carefully
